Argodiode 180-3AC 3 batteries 180A
From £80.14
RRP £66.62
Compared across 1 retailer
180A Schottky diode battery isolator for 3 batteries with alternator energize input, low voltage drop, and compensation diode for 12/24V systems.
- SKU
- ARG180301020
- Dimensions
- 65 x 120 x 200 mm
- Maximum Current
- 180A
- Number of Batteries
- 3
- Battery Voltage
- 12V / 24V
- Voltage Drop (low current)
- ~0.3V
Price Comparison
| Retailer | Price | Availability | Actions |
|---|---|---|---|
| Powerland | £80.14 | In Stock | Visit Site |
Price History
Full Specifications
| SKU | ARG180301020 |
|---|---|
| Dimensions | 65 x 120 x 200 mm |
| Maximum Current | 180A |
| Number of Batteries | 3 |
| Battery Voltage | 12V / 24V |
| Voltage Drop (low current) | ~0.3V |
| Voltage Drop (rated output) | ~0.45V |
| Alternator Energize Input | Yes (AC version) |
| Compensation Diode | Yes |
| Connection | M8 studs |
| Diode Type | Schottky |
About the Argodiode 180-3AC 3 batteries 180A
The Victron Argodiode 180-3AC allows simultaneous charging of three batteries from a single alternator without interconnecting them. Ideal for vessels or vehicles with starter, house, and bow-thruster batteries. Schottky diodes provide a low voltage drop of approximately 0.3V at low current and 0.45V at rated output. A compensation diode can slightly increase alternator output to offset the diode drop. The alternator energize input (AC version) provides a current-limited feed to the B+ terminal, ensuring the alternator starts charging even with the isolator in circuit. Rated for both 12V and 24V systems with M8 stud connections.
