MultiPlus 12/1200/50-16 120V VE.Bus
N/A
0 retailers
MultiPlus-II 48/15000/200-100
Price currently unavailable
15000VA 48V inverter/charger with 200A charger and 100A transfer switch
- SKU
- PMP481502200
- Dimensions
- 810 x 405 x 217 mm
- Battery voltage
- 48V
- Battery voltage range
- 38 - 66V
- AC input voltage range
- 187 - 265 VAC
- AC input frequency
- 45 - 65 Hz
Price Comparison
Price Comparison Unavailable
We're currently unable to find this product in stock at any of our tracked UK retailers. This can happen when a product is temporarily out of stock, discontinued, or newly released.
- Check back soon — we refresh prices hourly across all retailers
- View on Victron Energy website for official specifications
- Download datasheet (PDF)
- Download manual (PDF)
Price History
Not enough price history data available yet. Check back as we collect more pricing information.
Full Specifications
| SKU | PMP481502200 |
|---|---|
| Dimensions | 810 x 405 x 217 mm |
| Battery voltage | 48V |
| Battery voltage range | 38 - 66V |
| AC input voltage range | 187 - 265 VAC |
| AC input frequency | 45 - 65 Hz |
| Inverter output voltage | 230 VAC ± 2% |
| Continuous output power at 25°C | 15000 VA / 12000 W |
| Peak power | 25000 W |
| Maximum efficiency | 96% |
| Zero-load power | 35 W |
| Maximum charge current | 200A |
| Charge voltage absorption | 57.6V |
| Charge voltage float | 55.2V |
| Transfer switch rating | 100A |
| Powerassist | Yes |
| Communication port | VE.Bus |
| Programmable relay | Yes |
| Operating temperature | -40 to +65°C |
| Humidity | 95% non-condensing |
| Protection | IP22 |
| Parallel operation | Yes (up to 6) |
| Three-phase operation | Yes |
| GX device integration | Yes |
About the MultiPlus-II 48/15000/200-100
The MultiPlus-II is ideally suited for professional marine, yachting, vehicle and land based off-grid applications. Learn more now.
Application Guide
- Ideal for powering 230V appliances in motorhomes, campervans, boats and off-grid cabins from your battery bank.
- Choose the right size by totalling the wattage of all appliances you want to run simultaneously.
- Pair with a Victron MPPT solar charge controller and lithium batteries for a complete off-grid power system.
